Storage and breathing share a path
The training source describes activated charcoal holding fuel vapors until the engine purges them. The canister also sits in the system’s breathing path. That makes vapor storage and path restriction different diagnostic questions; a symptom alone does not identify the canister as the failed part.
Did this help you move forward?
Optional. No written response is collected.
Locate the restriction before naming the part
The Dart’s outlet path includes a canister, ESIM and remote filter. In the video, improved flow when the remote outlet was separated pointed downstream; dirt was found in the remote filter. The presenter replaced the filter and reported a successful fill-up.
| Reported finding | Interpretation | Outcome boundary |
|---|---|---|
| Repeated nozzle shutoff. | An outlet restriction was investigated. | The symptom alone did not condemn the canister. |
| Flow improved with the remote outlet separated. | The restriction was narrowed to that outlet path. | This does not establish a transferable disassembly procedure. |
| Filter replaced; fill-up reported successful. | The original complaint was revisited. | No long-term follow-up is shown. |
Watch the source in context
Video loads only when you choose to play.
Did this help you move forward?
Optional. No written response is collected.
Sources, review and limits
Prepared by GoTech with AI assistance. Source wording and the bounded educational interpretation were checked in two reasoning passes by the same assistant. Technician review is pending; vehicle-specific service information and visual details have not been independently verified. Original source files remain unchanged.
- Storage and breathing share a path
- Qualitative purge/seal training explanation; no capacity, contamination limit or universal replacement rule. Watch the source · 9:30
- Locate the restriction before naming the part
- 2014 Dodge Dart source report. The canister was not established as the cause of this refueling complaint. Watch the source · 3:40
About older links to this guide
This guide has been rewritten around the available source evidence. An older section link may land here; use “In this guide” above to find the revised explanation. Original source files are retained in GoTech’s review history.
